10L Sprayer Drone (JT10L-404QC)

Capacity: 10 liter
Work efficiency: 5-7 ha/hr
Battery: 1PC 14S 10000mAh
Availability:
Quantity:
sharethis sharing button
  • JT10L-404QC

  • JOYANCE

10L Drone Agriculture Sprayer

The latest smart appearance. The most affordable drone sprayer for beginner.

Aviation aluminum alloy drone frame, durable and stable;

Foldable drone sprayer arms, easy to transport;

Quick pluggable water tank;

14S 10000mAh smart battery, intelligent management system inside;

T12 remote controller with night vision FPV camera;

Multilingual language App for flight routes planning;

Standard obstacle avoidance function.


10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster


Standard kit:


10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster


Customized services:


10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster


Specification:

Model JT10L-404QC
Pesticide Tank 10L
Net Weight 13kg
Take-off Weight 27kg
Flying Time 10~15min
Flying Radius 0~1000m
Flying Height 0~30m
Flying Speed 0~12m/s
Work Temperature -10~70°C
Work Humidity 0~90%
Spray Speed 0~8m/s
Spray Width/Nozzle No. >3.5~5.5m / 4 Nozzles
Spray Flow 1~1.5L/min
Spray Efficiency 5~7Ha/Hr
Flying Downward Airflow 4~15m/s
Wind Resistance 10m/s
Machine Size Spread Size W1.14m x L1.12m x H0.58m
Folded Size W0.82m x L0.64m x H0.58m
Power System Motor Brushless
Propeller Carbon Fiber
ESC Rapid Throttle Response
Flight Control Joyance V8.3++ FC
Remote Controller Joyance Datalink T12 RC
Battery / Quantity 14S 10000mAh / 1pc
Adapter + Charger Dual-Channel Charger 2400W
Packing Case Aluminum Case
Toolkit Maintenance/Repair Tools

Detail Pictures:

Attention please, we are keeping improving our products, the actual drones are more beautiful, and there are some difference with following pictures. Please contact us for latest pictures.


10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster



10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster



10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster



10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster



10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster



10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster



10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster



10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster



10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster



10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster



10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster



10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster



10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster



10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster



10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster



10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster


Main functions:


10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster


Advantage:

1. Fashionable and independent research appearance, the waterproof of whole drone is IP56, spraying drone is suitable for working in the light rain.


10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster


2. The front-end control system and the back-end power supply system are independent, reasonable wiring, avoid electromagnetic interference, more stable and reliable, also easy to repair and replace.


10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster


3. Our services: we provide the longest warranty in the market of agricultural sprayer drones and sincere & timely services.


10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster


4. One brushless water pumps for 10L drone sprayer.

Brushless water pumps can be used for more than 500 hours, which are 3-5 times longer than ordinary water pumps , this is will reduce maintenance cost.

Voltage range: 12-14S

Max flow: 2 * 5L/min

Waterproof: IP 68 After finishing spraying, it can be washed with water directly to reduce pesticide corrosion.


10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster


5. JOYANCE agriculture sprayer drone with optional granule spreader can spread solid fertilizers/ granule fertilizer, seeds, sows, feed and so on.


10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster


6. Prompt delivery and shipment:Abundant finished products and sufficient spare parts in stock.


10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster


Production process:


10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster


The qualification certificates and patents certificates:


10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster



10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster


Attend in exhibitions:


10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster


Packing & transportation:


10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster


Global sales map:


10L Drone Agriculture Sprayer (JT10L-404QC)-drone agriculture sprayer, agriculture drone sprayer, sprayer drone, UAV crop duster


FAQ:

Q1. Are you sprayer drone factory?

A1: Yes, we are a professional manufacturer for sprayer drones.

Our main products are agricultural sprayer drones, spreader drones. thermal fogger drones, biological control drone.

Q2. Is uav sprayer drone ready to fly?

A2: Yes. Before dispatch, JOYANCE assemble all the parts and set all the parameters. Every drone is 100% flight tested and strict quality control.

Q3. What`s your MOQ of agricultural drone?

A3: MOQ ≥1. More than 100 units order is available. Besides, we are looking for dealers and agents all over the word. Welcome to contact us for more details.

Q4. What`s the delivery time of sprayer drone?

A4: 7 days for one, please contact us for mass order.

Q5. What`s your payment term?

A5: 50% payment as deposit, balance before delivery.
